Chapter 3 Removal and Replacement Procedures (RRPs)
Replacement
1) Install the OPERATION PANEL to the COVER TOP, and secure it using the 2 hooks.
2) Connect P/J1 of the OPERATION PANEL.
3) Secure the harnesses with the 2 clamps on the OPERATION PANEL.
4) Install the COVER TOP to the printer, and secure it to the COVER FRONT (PL 1.1) using the 2
hooks at the front of the COVER TOP.
5) Put the boss of the COVER OPEN (PL 1.1) into the hole of the LEVER LINK (PL 6.1.29).
When putting the boss of the COVER OPEN into the hole of the LEVER LINK, the
cover should be opened, and the LEVER LINK should be extended.
6) Secure the COVER TOP to the printer using the 2 screws (silver with flange, 8mm).
7) Install the 500 EXIT ASSEMBLY (PL 7.1) (RRP7.2).
When installing, put the harnesses of the MOTOR ASSEMBLY EXIT and HARNESS
ASSEMBLY EXIT SNR1 into the square hole of the frame.
8) Install the COVER EXIT 500 (PL 1.1) (RRP7.1).
9) Install the COVER LEFT (PL 1.1) (RRP1.3).
10) Install the COVER RIGHT (PL 1.1) (RRP1.2).
11) Install the COVER REAR (PL 1.1) (RRP1.1).
12) Install the COVER REAR 500 (PL 7.1) (RRP7.9).
