3 - 62
Chapter 3 Removal and Replacement Procedures (RRPs)
Replacement
1) Install the GEAR NUDGER to the SHAFT NUDGER (PL 4.1), and secure the GEAR NUDGER
with the hook.
When installing, do not touch the roller surface of the ROLL ASSEMBLY NUDGER and
GEAR NUDGER.
Be sure to install the hook of the GEAR NUDGER into the groove of the SHAFT
NUDGER.
2) Install the ROLL ASSEMBLY NUDGER (PL 4.1) to the SHAFT NUDGER, and secure the ROLL
ASSEMBLY NUDGER with the hook.
Be sure to install the hook of the ROLL ASSEMBLY NUDGER into the groove of the
SHAFT NUDGER.
3) Install the HOLDER LEFT (PL 4.1) and ACTUATOR NO PAPER (PL 4.1) to the SUPPORT
NUDGER (PL 12.3).
Be sure to install the shafts on both ends of the ACTUATOR NO PAPER into the
HOLDER LEFT and SUPPORT NUDGER.
Assemble the hook of the ACTUATOR NO PAPER to the HOLDER LEFT as shown (Fig-
ure 1).
4) Move the HOLDER LEFT (PL 4.1) in the opposite direction of the arrow, and secure it to the 150
FEEDER ASSEMBLY with the 3 hooks.
After installing, move the ACTUATOR NO PAPER with a finger, and make sure that the
ACTUATOR NO PAPER operates smoothly.
To Next Page
