3 - 66
Chapter 3 Removal and Replacement Procedures (RRPs)
When installing, make sure that the notch of the CLUTCH ASSEMBLY PH is combined
with the boss of the CHUTE REGI.
The harness of the CLUTCH ASY PH should be routed around the portion of the CHUTE
REGI as shown (Figure 1).
4) Connect the connector (P/J242) of the CLUTCH ASSEMBLY PH to the HARNESS ASSEMBLY
TRAY 1.
5) Install the 150 FEEDER ASSEMBLY (PL 4.1) (RRP4.1).
6) Install the CHUTE TRANSFER (PL 6.1) together with the BTR ASSEMBLY (RRP6.9).
Do not tighten the screw to the left side hole of the CHUTE TRANSFER.
7) Install the COVER REAR (PL 1.1) (RRP1.1).
There are 2 kinds of screws, make sure they are installed correctly.
8) Install the FUSER ASSEMBLY (PL 6.1) (RRP6.8).
9) Install the COVER REAR 500 (PL 7.1) (RRP7.9).
