3 - 75
Chapter 3 Removal and Replacement Procedures (RRPs)
1) Install the 550 FEEDER ASSEMBLY to the frame.
2) Secure the CHUTE OUT (PL 5.1) to the frame using the 2 screws (silver with flange, and spring
washer 8mm) (Figure 1).
One of the screws that secure the CHUTE OUT to the frame is tightened together with the
SPRING EARTH (PL 5.1.31).
3) Install the PLATE TIE (PL 5.1) to the frame using the 4 screws (silver with flange, and spring
washer 8mm).
4) Secure the harness using the 2 clamps on the PLATE TIE. (Refer to figures.)
When installing, put the harness into the notch on the PLATE TIE, and arrange it as
shown (Figure 1).
5) Connect the connector (P/J248) of the HARNESS ASSEMBLY TRAY 2 (PL 5.1) to the HARNESS
ASSEMBLY CHUTE (PL 9.1).
6) Install the 150 FEEDER ASSEMBLY (PL 4.1) (RRP4.1).
7) Install the CHUTE TRANSFER (PL 6.1) together with the BTR ASSEMBLY (RRP6.9).
Do not tighten the screw to the left side hole of the CHUTE TRANSFER.
8) Install the COVER REAR (PL 1.1) (RRP1.1).
There are 2 kinds of screws, make sure they are installed correctly.
9) Install the FUSER ASSEMBLY (PL 6.1) (RRP6.8).
10) Install the COVER REAR 500 (PL 7.1) (RRP7.9).
