3 - 77
Chapter 3 Removal and Replacement Procedures (RRPs)
When installing, do not touch the roller surface of the ROLL ASSEMBLY NUDGER and
ROLL ASSEMBLY FEED.
2) Install the ROLL ASSEMBLY NUDGER to the SHAFT NUDGER (PL 5.1), and secure the ROLL
ASSEMBLY NUDGER with the hook.
Be sure to install the hook of the ROLL ASSEMBLY NUDGER into the groove of the
SHAFT NUDGER.
3) Press the 150 FEEDER ASSEMBLY (PL 4.1) down so that it returns to the original position.
4) Install the Paper Cassettes to the Tray 1 and Tray 2.
5) Close the COVER OPEN (PL 1.1).
To Next Page
