3 - 79
Chapter 3 Removal and Replacement Procedures (RRPs)
Be sure to install the hook of the ROLL ASSEMBLY FEED into the groove of the SHAFT
FEED.
When installing, do not touch the roller surface of the ROLL ASSEMBLY FEED.
4) Press the 150 FEEDER ASSEMBLY (PL 4.1) down so that it returns to the original position.
5) Close the COVER OPEN (PL 1.1).
To Next Page
