Chapter 3 Removal and Replacement Procedures (RRPs)
Be careful of the arranging of the harness of the CLUTCH ASSEMBLY PH.
3) Install the PLATE TIE (PL 5.1) to the CHUTE OUT (PL 5.1) using the 6 screws (gold tapping,
8mm) (Figure 1).
4) Install the 550 FEEDER ASSEMBLY (PL 5.1) (RRP5.1).
5) Install the 150 FEEDER ASSEMBLY (PL 4.1) (RRP4.1).
6) Install the CHUTE TRANSFER (PL 6.1) (RRP6.9).
Do not tighten the screw to the left side hole of the CHUTE TRANSFER.
7) Install the COVER REAR (PL 1.1) (RRP1.1).
There are 2 kinds of screws, make sure they are installed correctly.
8) Install the FUSER ASSEMBLY (PL 6.1) (RRP6.8).
9) Install the COVER REAR 500 (PL 7.1) (RRP7.9).
