Chapter 3 Removal and Replacement Procedures (RRPs)
Replacement
1) Shift the GUIDE TRAY RIGHT in the opposite direction of the arrow to install it to the frame, and
secure it using the screw (silver, 6mm).
When installing the GUIDE TRAY RIGHT, make sure the installing position of the PLATE
CST LOCK (PL 5.1) is in the position shown (Figure 1) (NOTE).
2) Connect the connector (P/J260) of the HARNESS ASSEMBLY LOW PAPER SNR to the GUIDE
TRAY RIGHT (Figure 1).
3) Return the printer to the normal use state.
4) Install the COVER FRONT (PL 1.1) (RRP1.5).
5) Install the COVER TOP (PL 1.1) (RRP1.4).
6) Install the 500 EXIT ASSEMBLY (PL 7.1) (RRP7.2).
7) Install the COVER EXIT 500 (PL 1.1) (RRP7.1).
8) Install the COVER RIGHT (PL 1.1) (RRP1.2).
9) Install the COVER LEFT (PL 1.1) (RRP1.3).
10) Install the FUSER ASSEMBLY (PL 6.1) (RRP6.8).
11) Install the COVER REAR (PL 1.1) (RRP1.1).
There are 2 kinds of screws, make sure they are installed correctly.
12) Install the COVER REAR 500 (PL 7.1) (RRP7.9).
13) Install the EP CARTRIDGE and Paper Cassettes.
