3 - 89
Chapter 3 Removal and Replacement Procedures (RRPs)
3) Connect the connector (P/J1821) of the GUIDE TRAY LEFT to the HARNESS ASSEMBLY LVPS
(PL 9.1) (Figure 1).
4) Return the printer to the normal use state.
5) Install the COVER FRONT (PL 1.1) (RRP1.5).
6) Install the COVER TOP (PL 1.1) (RRP1.4).
7) Install the 500 EXIT ASSEMBLY (PL 7.1) (RRP7.2).
8) Install the COVER EXIT 500 (PL 1.1) (RRP7.1).
9) Install the COVER RIGHT (PL 1.1) (RRP1.2).
10) Install the COVER LEFT (PL 1.1) (RRP1.3).
11) Install the FUSER ASSEMBLY (PL 6.1) (RRP6.8).
12) Install the COVER REAR (PL 1.1) (RRP1.1).
There are 2 kinds of screws, make sure they are installed correctly.
13) Install the COVER REAR 500 (PL 7.1) (RRP7.9).
14) Install the EP CARTRIDGE and Paper Cassettes.
