Oki B6500

3 - 97
Chapter 3 Removal and Replacement Procedures (RRPs)
4) Connect the connector (P/J270) of the FAN SUB to the HARNESS ASSEMBLY LVPS (PL 9.1).
5) Install the COVER FRONT (PL 1.1) (RRP1.5).
6) Install the COVER TOP (PL 1.1) (RRP1.4).
7) Install the 500 EXIT ASSEMBLY (PL 7.1) (RRP7.2).
8) Install the COVER EXIT 500 (PL 1.1) (RRP7.1).
9) Install the COVER RIGHT (PL 1.1) (RRP1.2).
10) Install the COVER LEFT (PL 1.1) (RRP1.3).
11) Install the COVER REAR (PL 1.1) (RRP1.1).
There are 2 kinds of screws, make sure they are installed correctly.
12) Install the COVER REAR 500 (PL 7.2) (RRP7.9).
