1 – 9
Chapter 1 Troubleshooting
JS4 JS3 JS2 JS1 JS0
Contents of
Jam
Error Description
FIP to be
referred
1 0 0 0 1 Exit Jam 1
Paper Jam/Exit -When the paper was not
fed to Exit Sensor within the specified
time. - When Exit Sensor turned ON in
warming up.
FIP1.8
1 1 0 0 1 Exit Jam 2
Paper Jam/Exit - When paper was not
fed to Exit Sensor within the specified
time after SENSOR REGI OFF.
FIP1.8
0 0 0 0 1 Exit Jam 3
Paper Jam/Exit - When the paper was
fed out from Exit Sensor earlier than the
specified time.
FIP1.8
0 0 0 1 0
Feed Jam 1
(Early Feed
Jam)
Paper Jam/Tray to Regi -When the paper
was fed to Regi Sensor earlier than the
specified time. -Paper interval became
narrow than the specified time because
of the two or more papers are fed at a
time. -Paper size error. The paper longer
than Legal 14” is used.
FIP1.9
0 1 0 1 0
Feed Jam 2
(Misfeed
Jam)
Paper Jam/Misfeed -When the paper did
not reach Regi position within the speci-
fied time.
FIP1.10
0 1 0 1 1 Reg. Jam 1
Paper Jam/Regi to Fuser -When the
paper did not reach Fuser from Regi
position within the specified time.
FIP1.7
1 0 0 1 1 Reg. Jam 2
Paper Jam/Regi to Fuser - When Regi
Sensor turned ON in warming up.
FIP1.7
0 0 1 0 0 Duplex Jam 1
Paper Jam/Dup to Regi -When the paper
reached Regi position from Duplex Sen-
sor earlier than the specified time.
FIP2.4
0 1 1 0 0 Duplex Jam 2
Paper Jam/Exit to Dup -When the paper
did not reach Duplex Sensor within the
specified time.
FIP2.3
1 0 1 0 0 Duplex Jam 3
Paper Jam/Dup to Regi -When the paper
was not fed to Duplex Sensor within the
specified time. - When Duplex Sensor
turned ON in warming up.
FIP2.4
1 1 1 0 0
Duplex Jam 4
(Misfeed
Jam)
Paper Jam/Misfeed -When the paper did
not reach Regi position from Duplex Sen-
sor within the specified time.
FIP2.5
0 1 1 0 1 OCT Jam 1
Paper Jam/Exit to OCT - When the paper
did not reach to OCT Sensor from Exit
Sensor within the specified time.
FIP3.3
1 0 1 0 1 OCT Jam 2
Paper Jam/OCT -When the paper was
not fed to OCT Sensor within the speci-
fied time. - When OCT Sensor turned ON
in warming up.
FIP3.4
To Next Page
