3 - 115
Chapter 3 Removal and Replacement Procedures (RRPs)
Replacement
1) Install the GUIDE ASSEMBLY CRU R.
2) Put the harness of the GUIDE ASSEMBLY CRU R to the hole of the frame (Figure 1).
3) Install the GUIDE ASSEMBLY CRU R to the frame using the 3 screws (silver, 6mm) (Figure 1).
4) Connect the connector (P/J15) of the HARNESS ASSEMBLY ANT to the HVPS/MCU (PL 9.1.19).
5) Connect the connector (P/J31) of the GUIDE ASSEMBLY CRU R to the HVPS/MCU.
6) Install the DUCT FRONT (PL 6.1) (RRP6.2).
7) Install the SHIELD PLATE HVPS (PL 9.1) (RRP9.9).
8) Install the SHIELD ASSEMBLY ESS (PL 9.1) (RRP9.7).
9) Install the COVER FRONT (PL 1.1) (RRP1.5).
10) Install the COVER TOP (PL 1.1) (RRP1.4).
11) Install the 500 EXIT ASSEMBLY (PL 7.1) (RRP7.2).
12) Install the COVER EXIT 500 (PL 1.1) (RRP7.1).
13) Install the COVER RIGHT (PL 1.1) (RRP1.2).
14) Install the COVER LEFT (PL 1.1) (RRP1.3).
15) Install the FUSER ASSEMBLY (PL 6.1) (RRP6.8).
16) Install the COVER REAR (PL 1.1) (RRP1.1).
There are 2 kinds of screws, make sure they are installed correctly.
17) Install the COVER REAR 500 (PL 7.1) (RRP7.9).
18) Install the BTR ASSEMBLY (PL 6.1) (RRP6.9).
To Next Page
