3 - 117
Chapter 3 Removal and Replacement Procedures (RRPs)
Replacement
1) Assemble the LEVER LINK and LINK GEAR 3 as shown in the figure, and install them to the
GUIDE CRU LEFT (PL 6.1) (Figure 1).
2) Install the COVER GUIDE CRU (PL 6.1) and HARNESS ASSEMBLY FUSER (PL 6.1) to the
GUIDE CRU LEFT (RRP6.7).
3) Install the GUIDE CRU LEFT (RRP6.4).
When installing, make sure that the LEVER LINK (PL 6.1.29) is attached to the GUIDE
CRU LEFT.
After installing the GUIDE CRU LEFT, touch the LINK GEAR 3 with your finger. Make
sure the LINK GEAR 3 moves inward, when the LEVER LINK is pulled up.
4) Install the SHIELD PLATE LVPS (PL 9.1) (RRP8.1).
5) Install the MOTOR COVER (PL 8.1) (RRP8.1).
6) Install the GUIDE TRAY LEFT (PL 5.1) (RRP5.8).
7) Install the he SHIELD PLATE ROS (PL 6.1) (RRP6.3).
8) Install the ROS ASSEMBLY (PL 6.1) (RRP6.1).
Be careful not to drop or strike the ROS Assembly with any tools or other objects.
9) Install the DUCT FRONT (PL 6.1) (RRP6.2).
10) Install the COVER FRONT (PL 1.1) (RRP1.5).
11) Install the COVER TOP (PL 1.1) (RRP1.4).
12) Install the 500 EXIT ASSEMBLY (PL 7.1) (RRP7.2).
13) Install the COVER EXIT 500 (PL 1.1) (RRP7.1).
14) Install the COVER RIGHT (PL 1.1) (RRP1.2).
15) Install the COVER LEFT (PL 1.1) (RRP1.3).
16) Install the FUSER ASSEMBLY (PL 6.1) (RRP6.8).
17) Install the COVER REAR (PL 1.1) (RRP1.1).
There are 2 kinds of screws, make sure they are installed correctly.
18) Install the COVER REAR 500 (PL 7.1) (RRP7.9).
19) Install the BTR ASSEMBLY (PL 6.1) (RRP6.9).
