Chapter 3 Removal and Replacement Procedures (RRPs)
Replacement
1) Remove the LINK GATE OCT (PL 7.1) assembled into the removed CHUTE UP EXIT (Figure 1).
2) Secure the CHUTE UP EXIT to the CHUTE LOW EXIT using the 2 screws (gold tapping, 8mm)
(Figure 1).
3) Put the LINK GATE OCT under the 2 arms of the CHUTE UP EXIT as shown (Figure 1), and turn
it in the direction of the arrow.
4) Push the LINK GATE OCT in the direction of the arrow (shown in the area labeled figure 2) as far
as it will go.
After installing, make sure that the LINK GATE OCT is placed at the back side of the
GATE. (Note1) (Figure 1)
After installing, make sure that the tip of the LINK GATE OCT is placed under the hook of
the CHUTE LOW EXIT. (Note2) (Figure 1).
After installing, make sure that the GATE moves when the LINK GATE OCT is pushed in
the direction of the arrow. (Note2) (Figure 1)
5) Install the 500 EXIT ASSEMBLY (PL 7.1) (RRP7.2).
6) Install the COVER EXIT 500 (PL 1.1) (RRP7.1).
7) Install the COVER RIGHT (PL 1.1) (RRP1.2).
8) Install the COVER LEFT (PL 1.1) (RRP1.3).
9) Install the COVER REAR (PL 1.1) (RRP1.1).
There are 2 kinds of screws, make sure they are installed correctly.
10) Install the COVER REAR 500 (PL 7.1) (RRP7.9).
