3 - 140
Chapter 3 Removal and Replacement Procedures (RRPs)
Replacement
1) Install the MOTOR COVER to the frame using the screw (silver, 6mm) (Figure 1).
2) Install the harness connector of MAIN MOTOR(Figure 1).
3) Install the SHIELD PLATE ROS (PL 6.1) (RRP6.3).
4) Install the ROS ASSEMBLY (PL 6.1) (RRP6.1).
Be careful not to drop or strike the ROS Assembly with any tools or other objects.
5) Install the DUCT FRONT (PL 6.1) (RRP6.2).
6) Install the GUIDE TRAY LEFT (PL 5.1) (RRP5.8).
7) Install the COVER FRONT (PL 1.1) (RRP1.5).
8) Install the COVER TOP (PL 1.1) (RRP1.4).
9) Install the 500 EXIT ASSEMBLY (PL 7.1) (RRP7.2).
10) Install the COVER EXIT 500 (PL 1.1) (RRP7.1).
11) Install the COVER RIGHT (PL 1.1) (RRP1.2).
12) Install the COVER LEFT (PL 1.1) (RRP1.3).
13) Install the FUSER ASSEMBLY (PL 6.1) (RRP6.8).
14) Install the COVER REAR (PL 1.1) (RRP1.1).
There are 2 kinds of screws, make sure they are installed correctly.
15) Install the COVER REAR 500 (PL 7.1) (RRP7.9).
16) Install the BTR ASSEMBLY (PL 6.1) (RRP6.9).
To Next Page
