Oki B6500

3 - 151
Chapter 3 Removal and Replacement Procedures (RRPs)
Replacement
1) Install the LVPS to the frame using the 5 screws (silver, 6mm) (Figure 1).
2) Connect the harness connectors to the connectors (P/J40, P/J41, P/J42, P/J43, P/J44, P/J45, P/
J46, P/J47 and P/J48) on the LVPS (Figure 1).
3) Connect the connector of the harness LVPS to the connector (P/J101) on the PWBA EXIT
MOTOR (PL 12.1.4) (Figure 1).
4) Install the SHIELD PLATE LVPS (PL 9.1) (RRP8.1).
5) Install the COVER FRONT (PL 1.1) (RRP1.5).
6) Install the COVER TOP (PL 1.1) (RRP1.4).
7) Install the 500 EXIT ASSEMBLY (PL 7.1) (RRP7.2).
8) Install the COVER EXIT 500 (PL 1.1) (RRP7.1).
When installing, pull the CHUTE EXIT FUSER lever.
9) Install the COVER RIGHT (PL 1.1) (RRP1.2).
10) Install the COVER LEFT (PL 1.1) (RRP1.3).
11) Install the COVER REAR (PL 1.1) (RRP1.1).
There are 2 kinds of screws, make sure they are installed correctly.
12) Install the COVER REAR 500 (PL 7.1) (RRP7.9).
