Chapter 3 Removal and Replacement Procedures (RRPs)
Replacement
1) Install the POWER SWITCH to the frame (Figure 1).
2) Install the HARNESS ASSEMBLY AC100V/AC200V to the hole at the rear of the frame (Figure 1).
3) Secure the ground terminal of the HARNESS ASSEMBLY AC100V/AC200V to the frame using the
screw (silver with toothed washer, 6mm) (Figure 1).
4) Secure the HARNESS ASSEMBLY AC100V/AC200V.
5) Connect the connector (P/J48) of the HARNESS ASSEMBLY AC100V/AC200V to the LVPS (PL
9.1.5).
6) Connect the connector (P/J480) of the HARNESS ASSEMBLY AC100V/AC200V to the POWER
SWITCH.
7) Secure the HARNESS ASSEMBLY AC100V/AC200V using the clamps of the GEAR ASSEMBLY
HOUSING (PL 8.1.3).
8) Install the SHIELD PLATE LVPS (PL 9.1) (RRP8.1).
9) Install the COVER FRONT (PL 1.1) (RRP1.5).
10) Install the COVER TOP (PL 1.1) (RRP1.4).
11) Install the 500 EXIT ASSEMBLY (PL 7.1) (RRP7.2).
When installing, pull the CHUTE EXIT FUSER lever.
12) Install the COVER EXIT 500 (PL 1.1) (RRP7.1).
13) Install the COVER RIGHT (PL 1.1) (RRP1.2).
14) Install the COVER LEFT (PL 1.1) (RRP1.3).
15) Install the COVER REAR (PL 1.1) (RRP1.1).
There are 2 kinds of screws, make sure they are installed correctly.
16) Install the COVER REAR 500 (PL 7.1) (RRP7.9).
