3 - 172
Chapter 3 Removal and Replacement Procedures (RRPs)
Replacement
1) 1) Install the FAN DUPLEX to the COVER REAR using the 2 screws (gold tapping, 22mm).
When installing, be sure to install the FAN DUPLEX so that the label is facing outside.
2) Install the COVER REAR to the COVER HSG DUP using the 4 screws
3) Secure the harness of the FAN DUPLEX to the hook on the COVER HSG DUP.
4) Connect the harness connector to the connector (P/J54) on the PWBA DUPLEX (PL 10.1).
5) Install the COVER TOP (PL 10.1). (RRP10.4)
When installing, be sure to fit the positioning holes on the COVER TOP to the bosses on
the COVER HSG DUP.
6) Install the COVER RIGHT (PL 10.1). (RRP10.10)
When installing, be sure to fit the positioning holes on the COVER RIGHT to the bosses
on the COVER HSG DUP.
To Next Page
