3 - 175
Chapter 3 Removal and Replacement Procedures (RRPs)
Replacement
1) Move 3 ROLL DUPs in the opposite direction of the arrow, and install them to the BEARING
DUP (PL 10.1) on the GEAR ROLL (PL 10.1) side
To avoid contamination when installing the ROLL DUP, do not touch the rubber rollers.
2) Put the BEARING DUP into the ROLL DUP on the opposite side of the GEAR ROLL, and insert
it into the hole on the COVER HSG DUP (PL12.1.18), and then secure it with the hook.
3) Lock 3 GEAR ROLLs to the ROLL DUP with hook.
4) Install the COVER DAMPER (PL 10.1) and SPRING DAMPER (PL 10.1) to the COVR HSG
DUP using the 2 screws (gold tapping, 8mm) and the SCREW TAPPING (PL 10.1).
The SCREW TAPPING securing the COVER DAMPER is tightened together with the
SPRING DAMPER.
5) Install the HSG LOWER DUP (PL 10.1). (RRP10.3)
6) Install the HSG UPPER ASSY (PL 10.1). (RRP10.2)
7) Install the COVER RIGHT (PL 10.1). (RRP10.10)
When installing, be sure to fit the positioning holes on the COVER RIGHT to the bosses
on the COVER HSG DUP.
8) Install the COVER LEFT (PL 10.1). (RRP10.9)
When installing, be sure to fit the positioning holes on the COVER LEFT to the bosses on
the COVER HSG DUP.
