3 - 182
Chapter 3 Removal and Replacement Procedures (RRPs)
2) Connect the connector of the HARNESS ASSY DUP COVER (PL 10.1) to the connector (P/
J52) of the SWITCH DUPLEX.
3) Install the BRACKET MOTOR to the COVER HSG DUP (PL 10.1) using the 3 screws (gold
tapping, 8mm).
When installing the BRACKET MOTOR, be careful not to lose the gears.
4) Install the SPRING LATCH (PL 10.1) between the LEVER LATCH LEFT (PL 10.1) and
BRACKET MOTOR.
5) Install the HARNESS ASSY DUP EARTH (PL 10.1) using the screw (silver, 6mm).
6) Install the PWBA DUPLEX (PL 10.1). (RRP10.5)
When installing the PWBA DUPLEX, be careful in the installing direction.
7) Install the COVER TOP (PL 10.1). (RRP10.4)
When installing, be sure to fit the positioning holes on the COVER TOP to the bosses on
the COVER HSG DUP.
8) Install the COVER LEFT (PL 10.1). (RRP10.9)
When installing, be sure to fit the positioning holes on the COVER LEFT to the bosses on
the COVER HSG DUP.
To Next Page
