3 - 223
Chapter 3 Removal and Replacement Procedures (RRPs)
One of the screws that secure the PWBA FEEDER 550 is tightened together with the
FRAME TOP ASSY.
When installing, align the hole of the PWBA FEEDER 550 with the boss of the FRAME
CVR R550.
2) Connect the connectors (P/J80, P/J81, P/J82, P/J83, P/J84 and P/J85) on the PWBA FEEDER
550 to the harness connectors.
3) Install the COVER RIGHT PLATE (PL 12.1.1). (RRP12.2)
To Next Page
