3 - 263
Chapter 3 Removal and Replacement Procedures (RRPs)
Be sure to align the groove of the GUIDE INDICATOR 1 and the projection of the GUIDE
INDICATOR 3.
2) Insert the link lever of the GUIDE INDICATOR 1 (PL 12.3.34) to the hole of the PLATE ASSY
BTM.
3) Install the LOW INDICATOR (PL 12.3.37) and LOW IND FRONT (PL 12.3.38). (RRP12.26)
4) Install the HANDLE EXTENSION 550 (PL 12.3.41). (RRP12.23)
5) Install the COVER CST (PL 12.3.1) to the 5550 PAPER CASSETTE.
After assembling, make sure that the LOW IND FRONT moves up-and-down in conjunc-
tion with the up-and-down movement of the PLATE ASSY BTM
