6 – 15

Chapter 6 Principles of Operation

150 Paper Cassette:

550 Paper Cassette:

LEVER BTM LOC

K

LOCK EXTENSION

STOPPER GEAR

GUIDE ASSY END150

GUIDE ASSY SD R150

PLATE ASSY BTM

GUIDE ASSY SD L150

JG6117A

A

LEVER BTM LOC

K

LOCK EXTENSION

STOPPER GEAR

GUIDE ASSY END 550

GUIDE ASSY SD R550

PLATE ASSY BTM

GUIDE ASSY SD L 550

JG6017A

A

LOW INDICATOR

LOW IND FRONT

GUIDE INDICATOR
