Chapter 7 Wiring Diagrams and Signal Information
Represents a functional part within a part, and indicates the name of the functional
part.
Represents a section in "2. Interconnection Wiring Diagram of Parts," and indi-
cates its section No.
Represents a screw for fixing wiring harness and a conductive member such as a
plate spring.
Represents a conductive member such as a plate spring.
Symbols Description
