CAUTION
Risk of injury due to pressurised liquid
If installation, removal or maintenance work is not carried out correctly, there
is a risk of burns and other injuries at the connection points, if pressurised
hot water or hot steam suddenly escapes.
• Ensure proper installation, removal or maintenance work.
• Ensure that the system is de-pressurised before performing installation,
removal or maintenance work at the connection points.

Note!
When installing the on
-site safety valve, the operator must ensure that
there is no danger during blow-off.

Note!
Equipment parts with a safety function in respect of water
-side
pressure limiting according to the Pressure Equipment Directive
2014/68/EU and temperature limiting according to the Pressure
Equipment Direc
tive 2014/68/EU are not supplied.
The operator is responsible for on
-site provision of water-side pressure
and temperature protection.
4 Description of the device
4.1 Description
The Variomat with touch control is a pump-controlled pressure maintaining,
make-up and degassing station for heating and cooling water systems. The
Variomat is essentially a controller with pumps and at least one expansion tank.
The expansion tank is fitted with a diaphragm to divide the tank into an air space
and a water space. preventing the ingress of atmospheric oxygen into the
expansion water.
The Variomat with touch control provides the following safety features:
• Optimisation of all pressure maintaining, degassing and make-up
processes.
– No direct intake of air thanks to a regulation of the pressure
maintenance with automatic make-up.
– No circulation issues caused by free bubbles in the circuit water.
– Reduced corrosion damage due to oxygen removal from fill and
make-up water.
4.2 Overview
Variomat with touch control and two
pumps
Variomat with touch control and one
pump
1 Main switch 4 Degassing valve "DV"
2 Control unit
• Pump(s)
• "Reflex Control Touch"
controller
5 "VF" secondary vessel
6 "VF" primary vessel
7 Feed and drain cock "FD"
3 "VE" ventilation 8 "LIS" level sensor
4.3 Identification
4.3.1 Nameplate
The nameplate provides information about the manufacturer, the year of
manufacture, the manufacturing number and the technical data.
Information on the type plate
Meaning
Type Device name
Serial No. Serial number
Min. / max. allowable pressure PS
Minimum/maximum permissible
pressure
Max. allowable flow temperature of
system
Maximum permissible flow temperature
of the system
Min. / max. working temperature
TS
Min./max. operating temperature (TS)
Year of manufacture
Year of manufacture
Max. system pressure Max. system pressure
Min. operating pressure set up on
site
Minimum operating pressure, set on
site
4.3.2 Type code
No.
Type code (example)
1
Control unit
designation
2
Number of pumps
Variomat VS 2- 1, VG 500 l, VF 500 l
3
"VG" primary vessel
1 2 3 4 5 6
4
Nominal volume
5
"VF" secondary vessel
6
Nominal volume
4.4 Function
1 Heating system WV Make-up valve
2
"MAG" pressure
expansion vessel
PIS Pressure sensor
3 Reflex Fillset Impulse PV
Overflow valve (motor ball
valve)
4 Control unit PU Pump (pressure maintenance)
5 Hydraulic inlets SV Safety valve
6
Primary vessel air
chamber
EC Expansion line
7
Secondary vessel air
chamber
FD Feed and drain valve
ST Dirt trap LIS
Weight measuring cell For
determination of the water level
FQIRA+ Contact water meter DV Degassing valve
WC Make-up line VE Ventilation
