Remote control commands
R&S
®
RTP
1201User Manual 1337.9952.02 ─ 12
Parameters:
<Range> Voltage range value
Range: Dependencies see below.
Increment: Depends on vertical and probe settings
*RST: 0.5
Default unit: V/div
Depends on attenuation factors. With 1:1 probe and external
attenuation = 1, the range is 20 mV to 10 V. If the probe and/or
external attenuation is changed, multiply the range values by the
attenuation factors.
Usage: Asynchronous command
CHANnel<m>:POSition
<Position>
Sets the vertical position of the indicated channel as a graphical value.
Suffix:
<m>
.
1..4
Selects the input channel.
Parameters:
<Position> Positive values move the waveform up, negative values move it
down.
Range: -5 to 5
Increment: 0.01
*RST: 0
Default unit: div
Usage: Asynchronous command
CHANnel<m>:OFFSet <Offset>
The offset voltage is subtracted to correct an offset-affected signal. The offset of a sig-
nal is determined and set by the autoset procedure.
See also: "Offset" on page 160.
Suffix:
<m>
.
1..4
Selects the input channel.
Acquisition and setup
