Remote control commands
R&S
®
RTP
1404User Manual 1337.9952.02 ─ 12
Parameters for setting and query:
<HistogramName>
Usage: Asynchronous command
LAYout:HISTogram:RESet <HistogramName>
Resets the values to begin a new histogram.
Setting parameters:
<HistogramName>
Usage: Setting only
Asynchronous command
LAYout:HISTogram:REMove
<Name>
Removes the specified histogram.
Setting parameters:
<Name>
Usage: Setting only
Asynchronous command
22.12.7.2 Histogram measurement
This chapter lists commands to set up measurements on histograms.
Note that the R&S RTP performs histogram measurements on the measurement that is
defined with MEASurement<m>:MAIN. Other measurements are not considered.
See also: "Creating and reading histograms" on page 1130.
The following table lists the <MeasType> parameter values with a short description.
In addition, the suffixes <n> for limit check remote commands are listed.
For a detailed description, see Table 8-8.
Table 22-9: Histogram measurements
<MeasType>
parameter value
(remote control)
Measurement
(manual opera-
tion)
Description/Result Suffix
<n>
WCOunt Waveform count Number of acquisitions (waveforms) the histogram
is based on
1
WSAMples Waveform samples Number of samples from the most recent acquisition
included in the current histogram
2
HSAMples Histogram samples Number of samples from all acquisitions included in
the current histogram
3
HPEak Histogram peak Maximum sample value in the histogram 4
PEAK Peak value Signal value at the histogram peak 5
Automatic measurements
