TRIGger<m>:SPI:DPOPerator <DataPosOperator>
Sets the operator for the data position. You can defined an exact position, or a position
range.
Parameters:
<DataPosOperator> ANY | OFF | EQUal | GETHan | INRange | RANGe
ANY = OFF
The position of the required pattern is not relevant.
EQUal | GETHan
Equal, Greater or equal than. These conditions require one data
position to be set with TRIGger<m>:SPI:DPOSition.
INRange = RANGe
Set the minimum and maximum value of the range with
TRIGger<m>:SPI:DPOSition and TRIGger<m>:SPI:DPTO.
*RST: ANY
TRIGger<m>:SPI:DPOSition
<DataPosition>
Sets the number of bits or words to be ignored before the first bit or word od interest.
The effect is defined by TRIGger<m>:SPI:PALignment.
Parameters:
<DataPosition> The index 0 is associated with the first data byte.
Range: 0 to 4095 for triggering on one line (MISO or
MOSI), 2047 for triggering on both lines.
Increment: 1
*RST: 0
TRIGger<m>:SPI:DPTO <DataPositionTo>
Defines the last bit or word of interest, if TRIGger<m>:SPI:DPOPerator is set to
INRange.
Parameters:
<DataPositionTo> Range: 1 to 4095 for triggering on one line (MISO or
MOSI), 2047 for triggering on both lines.
Increment: 1
*RST: 1
TRIGger<m>:SPI:FCONdition <DataOperator>
Selects the operator for the MISO and MOSI pattern.
Parameters:
<DataOperator> EQUal | NEQual
*RST: EQUal
