Remote control commands
R&S
®
RTP
1711User Manual 1337.9952.02 ─ 12
22.17.9.1 Configuration
BUS<m>:ARINc:SOURce............................................................................................. 1711
BUS<m>:ARINc:BRValue..............................................................................................1711
BUS<m>:ARINc:BRMode..............................................................................................1711
BUS<m>:ARINc:MAXGap:SELect................................................................................. 1712
BUS<m>:ARINc:MAXGap:BITS.....................................................................................1712
BUS<m>:ARINc:MINGap:SELect...................................................................................1712
BUS<m>:ARINc:MINGap:BITS......................................................................................1712
BUS<m>:ARINc:POLarity............................................................................................. 1713
BUS<m>:ARINc:PRESet.............................................................................................. 1713
BUS<m>:ARINc:THReshold:HIGH.................................................................................1713
BUS<m>:ARINc:THReshold:LOW................................................................................. 1713
BUS<m>:ARINc:SOURce <SourceData>
Sets the channel for the signal source.
Reference and math waveforms are only available if the trigger source is one of the
input channels but not the serial bus.
Suffix:
<m>
.
1..4
Selects the serial bus.
Parameters:
<SourceData> C1W1 | C2W1 | C3W1 | C4W1 | M1 | M2 | M3 | M4 | M5 | M6 |
M7 | M8 | R1 | R2 | R3 | R4
*RST: C1W1
BUS<m>:ARINc:BRValue <BitRateValue>
Sets the number of transmitted bits per second.
Suffix:
<m>
.
1..4
Parameters:
<BitRateValue> Range: 10000 to 110000
Increment: 100
*RST: 100000
Default unit: bps
BUS<m>:ARINc:BRMode <BitRateMode>
Sets the bit rate mode to high or low speed.
Suffix:
<m>
.
1..4
Protocols
