Remote control commands
R&S
®
RTP
2260User Manual 1337.9952.02 ─ 12
Parameters:
<JittDatRateUnt> BIT_S | Hz
*RST: BIT_S
Usage: Asynchronous command
MEASurement<m>:JITTer:SKWSlope <JitterSkewSlope>
Sets the edge of the first waveform from which the skew delay or phase is measured:
positive, negative or both.
The command is available for the following measurement: skew delay and skew phase
(MEASurement<m>:MAIN and/or MEASurement<m>:ADDitional are set to mea-
surements SKWDelay | SKWPhase).
Suffix:
<m>
.
1..10
See "Selection of the measurement group: MEASurement<m>"
on page 1359.
Parameters:
<JitterSkewSlope> POSitive | NEGative | EITHer
*RST: POSitive
Usage: Asynchronous command
MEASurement<m>:JITTer:SKWRelation <JittskwRelt>
Sets the edge of the second waveform relative to the first waveform.
The command is available for the following measurements: skew delay and skew
phase (MEASurement<m>:MAIN and/or MEASurement<m>:ADDitional are set to
measurements SKWDelay | SKWPhase).
Suffix:
<m>
.
1..10
See "Selection of the measurement group: MEASurement<m>"
on page 1359.
Parameters:
<JittskwRelt> MATChing | INVerse
MATChing
Measures from positive to positive edge or from negative to neg-
ative edge.
INVerse
Measures from positive to negative edge or from negative to
positive edge.
*RST: MATChing
Usage: Asynchronous command
Jitter analysis and clock data recovery
