Measurements
R&S
®
RTP
321User Manual 1337.9952.02 ─ 12
● Starting a simple cursor measurement................................................................. 321
● Configuring a cursor measurement.......................................................................321
● Configuring the cursor display...............................................................................323
● Saving measurement results to file.......................................................................324
8.1.2.1 Starting a simple cursor measurement
To display cursors using the toolbar
1. Tap the "Cursor" icon on the toolbar.
2. Tap the waveform that you want to measure. Alternatively, you can draw a rectan-
gle in the diagram to position the cursor lines.
The cursor lines appear and the cursor results are displayed in a table or result
box.
To display cursors using the [Cursor] key
1. Select the waveform that you want to measure.
2. Press the [Cursor] key.
The cursor lines appear and the cursor results are displayed in a table or result
box.
To disable one cursor measurement
► If the results are shown in a floating result box, or in a result icon: Close the result
box or icon.
► If the results are shown in a docked table:
a) Tap the "Delete" icon on the toolbar.
b) Tap a cursor line.
The cursor set and its measurement results are deleted.
To disable all cursor measurements
► If the results are shown in a docked table:
a) Tap the "Delete" icon on the toolbar.
b) Tap the results table.
All cursor sets and measurement results are deleted.
8.1.2.2 Configuring a cursor measurement
To modify the position of the cursor lines, you can drag the lines on the screen. In addi-
tion, various settings are possible to refine the measurement.
Cursor measurements
