Configuration Guide Global IP-MAC Binding Commands
7.5 address-bind uplink
This command is used to configure the exception port. Use the no form of this command to restore
the default setting.
address-bind uplink interface-id
no address-bind uplink interface-id
Switching port or layer 2 aggregate port.
All ports are non-exception ports by default.
Global configuration mode.
If you have bound an IP address and a MAC address, the switch will discard the packets that have
the same source IP address but different source MAC address.
If the port is an exceptional port and is installed (see address-bind install), this binding policy does not
take effect.
The following example configures the exception port. Ruijie# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Ruijie(config)# address-bind uplink GigabitEthernet 0/1
Displays the exceptional port of address binding.
Use this command to display global IP address-MAC address binding.
