SINUS PENTA
PROGRAMMING GUIDE
100/486
P016 Speed Ramp 3: Deceleration Time
P016 Range
0 ÷ 32700
0 ÷327.00 s if P020=0 → 0.01 s
0 ÷3270.0 s if P020=0 → 0.1 s
0 ÷32700 s if P020=0 → 1 s
0
÷
327000 s if P020=0
→
10 s
Default
See Table 82 and Table 86
Level
ADVANCED
Address
616
Function Same as ramp 1 (see P010).
NOTE
Values for ramp 3 can be applied to the reference provided that multiramp digital inputs
are set up and that ramp 3 is selected (see the DIGITAL INPUTS MENU).
P018 Speed Ramp 4: Acceleration Time
P018 Range
0 ÷ 32700
0 ÷327.00 s if P020=0 → 0.01 s
0 ÷3270.0 s if P020=0 → 0.1 s
0 ÷32700 s if P020=0 → 1 s
0 ÷327000 s if P020=0 → 10 s
Default
See Table 82 and Table 86
Level
ADVANCED
Address
618
Function Same as ramp 1 (see P009).
NOTE
Values for ramp 4 can be applied to the reference provided that multiramp digital inputs
are set up and that ramp 4 is selected (see the DIGITAL INPUTS MENU).
P019 Speed Ramp 4: Deceleration Time
P019 Range
0 ÷ 32700
0 ÷327.00 s if P020=0 → 0.01 s
0 ÷3270.0 s if P020=0 → 0.1 s
0 ÷32700 s if P020=0 → 1 s
0
÷
327000 s if P020=0
→
10 s
Default
See Table 82 and Table 86
Level
ADVANCED
Address
619
Function Same as ramp 1 (see P010).
NOTE
Values for ramp 4 c
an be applied to the reference provided that multiramp digital inputs
are set up and that ramp 4 is selected (see the DIGITAL INPUTS MENU).
