Santerno Sinus Penta - Page 99

PROGRAMMING GUIDE
SINUS PENTA
99/486
P013 Speed Ramp 2: Deceleration Time
P013 Range
0 ÷ 32700
0 ÷327.00 s if P014=0 → 0.01 s
0 ÷3270.0 s if P014=0 → 0.1 s
0 ÷32700 s if P014=0 → 1 s
0
÷
327000 s if P014=0
→
10 s
Default
See Table 82 and Table 86
Level
ADVANCED
Address
613
Function Same as ramp 1 (see P010).
NOTE
Values for ramp 2 can be applied to the reference provided that multiramp digital inputs
are set up and that ramp 2 is selected (see the DIGITAL INPUTS MENU).
P014 Speed Ramps 1 and 2: Time Unit of Measure
P014 Range
0 ÷ 3
0 → 0.01 s
1→ 0.1 s
2→ 1 s
3→ 10 s
Default
See Table 82 and Table 86
Level
ADVANCED
Address
614
Function
Defines the unit of measure for the time periods for speed ramp 1 (P009 and P010),
for speed ramp 2 (P012 and P013), and for ramps in Fire Mode (P032 and P033
).
The allowable programmable range may be extended from 0 s to 327000s.
E.g.
P014=1 then P009=100; this means P009 = 100 x 0.1 s = 10 s
P014=0 then P009=100; this means P009 = 100 x 0.01 s = 1 s
P014=3 then P009=100; this means P009 = 100 x 10 s = 1000 s
P015 Speed Ramp 3: Acceleration Time
P015 Range
0 ÷ 32700
0 ÷327.00 s if P020=0 → 0.01 s
0 ÷3270.0 s if P020=0 → 0.1 s
0 ÷32700 s if P020=0 → 1 s
0 ÷327000 s if P020=0 → 10 s
Default
See Table 82 and Table 86
Level
ADVANCED
Address
615
Function Same as ramp 1 (see P009).
NOTE
Values for ramp 3 can be applied to the reference provided that multiramp digital inputs are
set up and that ramp 3 is selected (see the DIGITAL INPUTS MENU).
