SINUS PENTA
PROGRAMMING GUIDE
120/486
P067 Keypad and Terminal Board UP/DOWN Ramp
P067
Range
0 ÷ 6501
0 sec ÷ 6500s Quadratic
Default
6501
Quadratic
Level
ADVANCED
Address
667
Function
Reference may be increased or decreased with input digital signals UP and DOWN,
or using the ▲ and ▼ keys from the keypad (local mode).
Reference increment or decrement is obtained by adding to the current reference a
quantity which will be increased or decreased with a time ramp.
Parameter P067 indicates the ramp time to increase the reference f
rom zero to the
preset speed (or torque) maximum absolute value, i.e. the max. value between
absolute values Spd_Min and Spd_Max (or Trq_Min and Trq_Max).
If motor 1 is active, Spd_Min=C028, Spd_Max=C029, Trq_Min=C047
,
Trq_Max=C048.
P068 Storage of UP/DOWN Values at Power Off
P068
Range
0 ÷ 1
0: Disabled, 1: Enabled
Default
1
1: Enabled
Level
ADVANCED
Address
668
Function
If P068=1, the Speed/Torque or PID references added through input digital signals
UP and DOWN or with the INC and DEC keys (lo
cal mode), are stored at the drive
power off and are added to the start reference when the drive is restarted.
This function allows storing he reference value obtained with UP and DOWN signals.
P068a Reset UP/DOWN Speed/Torque at Stop
P068a
Range
0 ÷ 1
0: NO, 1: YES
Default
0
0: NO
Level
ADVANCED
Address
940
Function
If P068a =1: [Yes], the Speed/Torque reference sent via the UP/DOWN digital signals
or with the ▲ and ▼ keys in the keypad
is reset whenever the START command for
the drive is disabled and the deceleration ramp is finished.
P068b Reset UP/DOWN PID at Stop
P068b
Range
0 ÷ 1
0: NO, 1: YES
Default
0
0: NO
Level
ADVANCED
Address
941
Function
If P068b =1: [Yes], the PID reference sent via the UP/DOWN digital signals or via the
▲ and ▼ keys in the keypad
) is reset whenever the START command for the drive is
disabled and the deceleration ramp is finished.
