PROGRAMMING GUIDE
SINUS PENTA
125/486
P080 Multispeed Function
P080 Range
0 ÷ 2
0: Preset Speed,
1: Sum Speed,
2: Exclusive Preset Speed
Default
0
0: Preset Speed
Level
BASIC
Address
680
Function
Defines the functionality of the multispeed values for the global speed reference.
Three functions are available:
• 0: [ Preset Speed ] → the selected multispeed
is the actual rpm value (upon limit
due to min. and max. speed parameters for the selected motor) of the motor speed
reference. If no multispeed is selected (
no digital input programmed for multispeed
selection is activated, or all digital input
s programmed for multispeed selection are
deactivated
), the speed reference is the reference for the sources set in the
CONTROL METHOD MENU.
• 1: [ Sum Speed ] → the reference relating to the selected multispeed i
s
considered as the sum of the references for the other reference sources selected in
the CONTROL METHOD MENU.
• 2: [ Exclusive Preset Speed ] →
the selected multispeed is the actual rpm value
(upon saturation due
to min. and max. speed parameters for the selected motor) of
the motor speed reference. Unlike function 0 [Preset Speed], if no multispeed is
selected (
no digital input programmed for multispeed selection is activated, or all
digital inputs programmed for multispeed selection are deactivated)
the speed
reference is zero.
P081 to P098 Output Speed Mspd n.1 (/15)
P081÷P098
Range
–32000 ÷ 32000
±32000 rpm
Default
0
0.00 rpm
Level
From P081 to P085: BASIC
From P087 to P098: ADVANCED
Address
681÷698
Function
This parameter sets the multispeed output speed selected through the relevant
digital inputs (Table 101
). The multispeed value is scaled based on the unit of
measure set in P100.
The reference resulting f
rom the multispeed selected through the relevant digital
inputs will be computed based on the setting of parameter P080.
