Santerno Sinus Penta - Page 162

SINUS PENTA
PROGRAMMING GUIDE
162/486
P203 Max. FOUT Value of Selected Variable
P203 Range
–32000 ÷ +32000
Depends on the value
selected through P201
–320.00 % ÷ +320.00 % of the full-scale value
See Table 36
Default
0
0
Level
ADVANCED
Address
803
Function
Maximum value of the selected variable.
P204 Min. FOUT Output Value with Reference to P202
P204
Range
1000÷10000
10.00÷100.00 kHz
Default
1000
10.00 kHz
Level
ADVANCED
Address
804
Function
Minimum output value obtained when the minimum value of the variable set in
P202 is implemented.
P205 Min. FOUT Output Value with Reference to P203
P205
Range
1000÷10000
10.00÷100.00 kHz
Default
10000
100.00 kHz
Level
ADVANCED
Address
805
Function
Maximum output value obtained when the maximum value of the variable set in
P203 is implemented.
P206 Filter for FOUT Frequency Output
P206
Range
0 ÷ 65000
0.000 ÷ 65.000 sec
Default
0
0.000 sec.
Level
ADVANCED
Address
806
Function
Value of the filter time constant applied to FOUT frequency output.
P207 AO1: Gain
P208 AO2: Gain
P209 AO3: Gain
P210 AO1: Variable MODBUS Address
P211 AO2: Variable MODBUS Address
P212 AO3: Variable MODBUS Address
RESERVED
P213 Amplitude of Sinusoidal Analog Output Signal
P213
Range
0 ÷ 1000
0 ÷ 100.0%
Default
1000
100.0%
Level
ENGINEERING
Address
813
Function
Amplitude of the sinusoidal analog output signal when Sine or Cosine variables
are selected.
