PROGRAMMING GUIDE
SINUS PENTA
161/486
P198 Min. AO3 Output Value with Reference to P194
P198 Range
–100 ÷ +100
–200 ÷ +200
Function according to the
selection of P192
–10.0 ÷ +10.0 V
–20.0 ÷ +20.0 mA
Default
0 00.0 V
Level
ADVANCED
Address
798
Function
Minimum output value obtained when the minimum value of the variable set in
P194 is implemented.
P199 Max. AO3 Output Value with Reference to P195
P199 Range
–100 ÷ +100
–200 ÷ +200
Function according to
selection of P192
–10.0 ÷ +10.0 V
–20.0 ÷ +20.0 mA
Default
+100
+10.0 V
Level
ADVANCED
Address
799
Function
Maximum output value obtained when the maximum value of the variable set in
P195 is implemented.
P200 FOUT Output in [MDO1] Frequency
P200 Range
0 ÷ 2
0: Disabled,
1: Pulse,
2: ABS Pulse
Default
0
0: Disabled
Level
ADVANCED
Address
800
Function
Selects the operating mode of FOUT frequency output.
NOTE
When P200
is not set to DISABLE, MDO1digital output is used as a frequency output
and any settings for MDO1 in the DIGITAL OUTPUTS MENU are ignored.
P201 Selected Variable for FOUT Frequency Output
P201
Range
0
÷
69
See Table 36
Default
1
Motor speed
Level
ADVANCED
Address
801
Function
Selects the variable to be allocated to FOUT frequency output.
P202 Min. FOUT Value of Selected Variable
P202 Range
–32000 ÷ +32000
Depends on the value
selected through P201
–320.00 % ÷ +320.00 % of the full-scale value
See Table 36
Default
0
0
Level
ADVANCED
Address
802
Function
Minimum value of the selected variable.
