SINUS PENTA
PROGRAMMING GUIDE
190/486
Selectable Value
Description
D33: Fan Flt
Fault of the cooling fan
D34: Fbus C1
Command 1 from fieldbus
D35: Fbus C2
Command 2 from fieldbus
D36: Fbus C3
Command 3 from fieldbus
D37: Fbus C4
Command 4 from fieldbus
D38: FireMod
Fire Mode function
D39: Local
LOCAL Mode
D40: Speed OK
Constant speed reference reached
D41: Fan ON
Fan activation command
D42: XMDI1
XMDI1 Auxiliary digital input
D43: XMDI2
XMDI2 Auxiliary digital input
D44: XMDI3
XMDI3 Auxiliary digital input
D45: XMDI4
XMDI4 Auxiliary digital input
D46: XMDI5
XMDI5 Auxiliary digital input
D47: XMDI6
XMDI6 Auxiliary digital input
D48: XMDI7
XMDI7 Auxiliary digital input
D49: XMDI8
XMDI8 Auxiliary digital input
D50: MPL 1 Delayed
Virtual digital input resulting from MPL1 output DELAYED from MPL Timers
D51: MPL 2 Delayed
Virtual digital input resulting from MPL2 output DELAYED from MPL Timers
D52: MPL 3 Delayed
Virtual digital input resulting from MPL3 output DELAYED from MPL Timers
D53: MPL 4 Delayed
Virtual digital input resulting from MPL4 output DELAYED from MPL Timers
D54: OTM Elapsed
Maintenance Operation Time elapsed
D55: STM Elapsed
Maintenance Supply Time elapsed
D56: MDO 1 Delayed
Virtual digital input resulting from MDO1 output DELAYED from MDO Timers
D57: MDO 2 Delayed
Virtual digital input resulting from MDO2 output DELAYED from MDO Timers
D58: MDO 3 Delayed
Virtual digital input resulting from MDO3 output DELAYED from MDO Timers
D59: MDO 4 Delayed
Virtual digital input resulting from MDO4 output DELAYED from MDO Timers
D60: TFL1
Timed flag TFL1
D61: TFL2
Timed flag TFL2
D62: TFL3
Timed flag TFL3
D63: TFL4
Timed flag TFL4
D64: NTC Fault
NTC Fault (heatsink temperature measurement)
D65: Cumulative Warning
Logic OR of W40 (FAN FAULT), W50 (NTC FAULT), W48 (OT TIME OVER), W49 (ST TIME
OVER)
D66: Dec to Stop
Deceleration due to START opening or STOP activation
D67: Reserved
D68: Accelerating
Motor accelerating
D69: Decelerating
Motor decelerating
D70-D79: Reserved
