Santerno Sinus Penta - Page 208

SINUS PENTA
PROGRAMMING GUIDE
208/486
P282 MDO2: Testing Variable A
P282 Range
0 ÷ 7
0: >
1: ≥
2: <
3: ≤
4: ABS(x) >
5: ABS(x) ≥
6: ABS(x) <
7: ABS(x) ≤
Default
0
0: >
Level
ADVANCED
Address
882
Function
This parameter defines the test to be performed for the variable detected by P280
using P284 as a comparing value.
P283 MDO2: Testing Variable B
P283 Range
0 ÷ 7
0: >
1: ≥
2: <
3: ≤
4: ABS(x) >
5: ABS(x) ≥
6: ABS(x) <
7: ABS(x)
≤
Default
0
3: ≤
Level
ADVANCED
Address
883
Function
This parameter defines the test to be performed for the variable detected by P281
using P285 as a comparing value.
P284 MDO2: Comparing Value for Test A
P284 Range
–32000 ÷ 32000
–320.00 % ÷ 320.00 %
% of the full-scale value of selected variable A, see Table 48
Default
2000
20%
Level
ADVANCED
Address
884
Function
This parameter defines the comparing value with the selected variable for test A.
P285 MDO2: Comparing Value for Test B
P285 Range
–32000 ÷ 32000
–320.00 % ÷ 320.00 %
% of the full-scale value of selected variable B, see Table 48
Default
50
50 rpm
Level
ADVANCED
Address
885
Function
This parameter defines the comparing value with the selected variable for test B.
