P278 MDO1: Output Logic Level
P278 Range 0–1
0: FALSE
1: TRUE
Default
1
1: TRUE
Level
ADVANCED
Address
878
Function
MDO1 digital output logic function to apply a logic reversal (negation) to the
calculated output signal: (0) FALSE = a logic negation is applie
d; (1) TRUE = no
negation is applied.
P279 MDO2: Digital Output Mode
P279 Range
0 ÷ 9
0: DISABLE
1: DIGITAL
2: DOUBLE DIGITAL
3: ANALOG
4: DOUBLE ANALOG
5: DOUBLE FULL
6: BRAKE
7: ABS BRAKE
8: ABS LIFT
9: PWM MODE
Default
6
1: BRAKE
Level
ADVANCED
Address
879
Function
This parameter defines the operating mode of digital output 2. The different
operating modes are described at the beginning of this chapter.
P280 MDO2: Selecting Variable A
P280
Range
0 ÷ 149
See Table 48
Default
71
A11: Torque Output
Level
ADVANCED
Address
880
Function
This parameter selects the digital signal used to calculate the value of MDO2
digital output.
It selects an analog variable used to calculate the value of MDO2 digi
tal input if
one of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
P281 MDO2: Selecting Variable B
P281
Range
0 ÷ 149
See Table 48
Default
61
A01: Speed MEA
Level
ADVANCED
Address
881
Function
This parameter selects the second digital signal used to calculate the value of
MDO2 digital output.
It selects an analog variable used to calculate the value of MDO2
digital input if
one of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
