P277 MDO1: Function Applied to the Result of the 2 Tests
P277 Range
0 ÷ 12
0: (A) OR (B)
1: (A) SET (B) RESET
2: (A) AND (B)
3: (A) XOR (B)
4: (A) NOR (B)
5: (A) NAND (B)
6: (A\) OR (B)
7: (A) OR (B\)
8: (A\) AND (B)
9: (A) AND (B\)
10: (A) RESET (B) SET RISING EDGE
11: (A) SET (B) RESET FALLING EDGE
12: (A) RESET (B) SET FALLING EDGE
Default
1
1: (A) SET (B) RESET
Level
ADVANCED
Address
877
Function
This parameter determines the logic function applied to the result of the t
wo
tests allowing calculating the output value.
P277a MDO1: Selecting Variable C
277a
Range
0 ÷ 79
See Table 48
Default
0
D0: Disable
Level
ADVANCED
Address
642
Function
This parameter selects the digital signal used to calculate the value of MDO1
digital output.
The digital signals that can be selected are given in Table 48.
P277b MDO1: Function Applied to the Result of f(A,B) C
P277b Range
0 ÷ 12
0: f(A,B) OR (C)
1: f(A,B) SET (C) RESET RISING EDGE
2: f(A,B) AND (C)
3: f(A,B) XOR (C)
4: f(A,B) NOR (C)
5: f(A,B) NAND (C)
6: f(A,B)\ OR (C)
7: f(A,B) OR (C\)
8: f(A,B)\ AND (C)
9: f(A,B) AND (C\)
10: f(A,B) RESET (C) SET RISING EDGE
11: f(A,B) SET (C) RESET FALLING EDGE
12: f(A,B) RESET (C) SET FALLING EDGE
Default
0
0: f(A,B) OR (C)
Level
ADVANCED
Address
643
Function
This parameter determines the logic function applied to the result of the two
tests allowing calculating the output value.
