P273 MDO1: Testing Variable A
P273 Range
0 ÷ 7
0: >
1: ≥
2: <
3: ≤
4: ABS(x) >
5: ABS(x) ≥
6: ABS(x) <
7: ABS(x) ≤
Default
0
0: >
Level
ADVANCED
Address
873
Function
This parameter defines the test to be performed for the variable detected by P271
using P275 as a comparing value.
P274 MDO1: Testing Variable B
P274 Range
0 ÷ 7
0: >
1: ≥
2: <
3: ≤
4: ABS(x) >
5: ABS(x) ≥
6: ABS(x) <
7: ABS(x) ≤
Default
3
3: ≤
Level
ADVANCED
Address
874
Function
This parameter defines the test to be performed for the variable detected by P272
using P276 as a comparing value.
P275 MDO1: Comparing Value for Test A
P275 Range
–32000 ÷ 32000
–320.00 % ÷ 320.00 %
% of the full-scale value of selected variable A, see Table 48
Default
50
50 rpm
Level
ADVANCED
Address
875
Function
This parameter defines the comparing value with the selected variable for test A.
P276 MDO1: Comparing Value for Test B
P276 Range
–32000 ÷ 32000
–320.00 % ÷ 320.00 %
% of the full-scale value of selected variable B, see Table 48
Default
10
10 rpm
Level
ADVANCED
Address
876
Function
This parameter defines the comparing value with the selected variable for test B.
