P287 MDO2: Output Logic Level
P287 Range 0–1
0: FALSE
1: TRUE
Default
1
1: TRUE
Level
ADVANCED
Address
887
Function
MDO2 digital output logic function to apply a logic reversal (negation) to the
calculated output signal: (0) FALSE = a logic negation is applied; (1) TRUE = no
negation is applied.
P288 MDO3: Digital Output Mode
P288 Range
0 ÷ 8
0: DISABLE
1: DIGITAL
2: DOUBLE DIGITAL
3: ANALOG
4: DOUBLE ANALOG
5: DOUBLE FULL
6: BRAKE
7: ABS BRAKE
8: ABS LIFT
Default
1
1: DIGITAL
Level
ADVANCED
Address
888
Function
This parameter defines the operating mode of digital output 3. The different
operating modes are described at the beginning of this chapter.
P289 MDO3: Selecting Variable A
P289
Range
0 ÷ 149
See Table 48
Default
3
D3: Inverter Alarm
Level
ADVANCED
Address
889
Function
This parameter selects the digital signal used to calculate the value of MDO3
digital output.
It selects an analog variable used to calculate the value of MDO3
digital input if
one of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48
P290 MDO3: Selecting Variable B
P290
Range
0 ÷ 149
See Table 48
Default
3
D3: Inverter Alarm
Level
ADVANCED
Address
890
Function
This parameter selects the second digital signal used to calculate the value of
MDO3 digital output.
It selects an analog variable used to calculate the value of digital input MDO3
if
one of the “analog” operating modes is selected.
Digital signals and analog variables detailed in Table 48.
