Santerno Sinus Penta - Page 211

PROGRAMMING GUIDE
SINUS PENTA
211/486
P291 MDO3: Testing Variable A
P291 Range
0 ÷ 7
0: >
1: ≥
2: <
3: ≤
4: ABS(x) >
5: ABS(x) ≥
6: ABS(x) <
7: ABS(x) ≤
Default
0
0: >
Level
ADVANCED
Address
891
Function
This parameter defines the test to be performed for the variable detected by P289
using P293 as a comparing value.
P292 MDO3: Testing Variable B
P292 Range
0 ÷ 7
0: >
1: ≥
2: <
3: ≤
4: ABS(x) >
5: ABS(x) ≥
6: ABS(x) <
7: ABS(x) ≤
Default
0
0: >
Level
ADVANCED
Address
892
Function
This parameter defines the test to be performed for the variable detected by P290
using P294 as a comparing value.
P293 MDO3: Comparing Value for Test A
P293 Range
–32000 ÷ 32000
–320.00 % ÷ 320.00 %
% of the full-scale value of selected variable A, see Table 48
Default 0 0
Level
ADVANCED
Address
893
Function
This parameter defines the comparing value with the variable selected for test A.
P294 MDO3: Comparing Value for Test B
P294 Range
–32000 ÷ 32000
–320.00 % ÷ 320.00 %
% of the full-scale value of selected variable B, see Table 48
Default
0
0
Level
ADVANCED
Address
894
Function
This parameter defines the comparing value with the variable selected for test B.
