Santerno Sinus Penta - Page 213

PROGRAMMING GUIDE
SINUS PENTA
213/486
P296 MDO3: Output Logic Level
P296 Range
0–1
0: FALSE
1: TRUE
Default 0 0: FALSE
Level
ADVANCED
Address
896
Function
MDO3 digital output logic function to apply a logic reversal (negation) to the
calculated output signal: (0) FALSE = a logic negation is applied; (1) TRU
E =
no negation is applied.
P297 MDO4: Digital Output Mode
P297 Range
0 ÷ 8
0: DISABLE
1: DIGITAL
2: DOUBLE DIGITAL
3: ANALOG
4: DOUBLE ANALOG
5: DOUBLE FULL
6: BRAKE
7: ABS BRAKE
8: ABS LIFT
Default
1
1: DIGITAL
Level
ADVANCED
Address
897
Function
This parameter defines the operating mode of digital output 4. The different
operating modes are described at the beginning of this chapter.
P298 MDO4: Selecting Variable A
P298
Range
0 ÷ 149
See Table 48
Default
1
D1: Inverter Run Ok
Level
ADVANCED
Address
898
Function
This parameter selects the digital signal used to calculate the value of MDO4 digital
output.
It selects an analog variable used to calculate the value of MDO4
digital input if one
of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
P299 MDO4: Selecting Variable B
P299
Range
0 ÷ 149
See Table 48
Default
1
D1: Inverter Run Ok
Level
ADVANCED
Address
899
Function
This parameter selects the second digital signal used to calculate the value of
MDO4 digital output.
It selects an analog variable used to calculate the value of MDO4 digital input i
f one
of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
