P300 MDO4: Testing Variable A
P300 Range
0 ÷ 7
0: >
1: ≥
2: <
3: ≤
4: ABS(x) >
5: ABS(x) ≥
6: ABS(x) <
7: ABS(x) ≤
Default
0
0: >
Level
ADVANCED
Address
900
Function
This parameter defines the test to be performed for the variable detected by P298
using P302 as a comparing value.
P301 MDO4: Testing Variable B
P301 Range
0 ÷ 7
0: >
1: ≥
2: <
3: ≤
4: ABS(x) >
5: ABS(x) ≥
6: ABS(x) <
7: ABS(x) ≤
Default
0
0: >
Level
ADVANCED
Address
901
Function
This parameter defines the test to be performed for the variable detected by P299
using P303 as a comparing value.
P302 MDO4: Comparing Value for Test A
P302 Range
–32000 ÷ 32000
–320.00 % ÷ 320.00 %
% of the full-scale value of selected variable A, see Table 48
Default
0
0
Level
ADVANCED
Address
902
Function
This parameter defines the comparing value with the selected variable for test A.
P303 MDO4: Comparing Value for Test B
P303 Range
–32000 ÷ 32000
–320.00 % ÷ 320.00 %
% of the full-scale value of selected variable B, see Table 48
Default
0
0
Level
ADVANCED
Address
903
Function
This parameter defines the comparing value with the selected variable for test B.
