Santerno Sinus Penta - Page 215

PROGRAMMING GUIDE
SINUS PENTA
215/486
P304 MDO4: Function Applied to the Result of the 2 Tests
P304 Range
0 ÷ 12
0: (A) OR (B)
1: (A) SET (B) RESET
2: (A) AND (B)
3: (A) XOR (B)
4: (A) NOR (B)
5: (A) NAND (B)
6: (A\) OR (B)
7: (A) OR (B\)
8: (A\) AND (B)
9: (A) AND (B\)
10: (A) RESET (B) SET RISING EDGE
11: (A) SET (B) RESET FALLING EDGE
12: (A) RESET (B) SET FALLING EDGE
Default
0
0: (A) OR (B)
Level
ADVANCED
Address
904
Function
This parameter determines the logic function applied to the result of the two
tests allowing calculating the output value.
P304a MDO4: Selecting Variable C
P304a
Range
0 ÷ 79
See Table 48
Default
0
D0: Disable
Level
ADVANCED
Address
648
Function
This parameter selects the digital signal used to calculate the value of
MDO4
digital output.
The digital signals that can be selected are given in Table 48.
P304b MDO4: Function Applied to the Result of f(A,B) C
P304b Range
0 ÷ 12
0: f(A,B) OR (C)
1: f(A,B) SET (C) RESET RISING EDGE
2: f(A,B) AND (C)
3: f(A,B) XOR (C)
4: f(A,B) NOR (C)
5: f(A,B) NAND (C)
6: f(A,B)\ OR (C)
7: f(A,B) OR (C\)
8: f(A,B)\ AND (C)
9: f(A,B) AND (C\)
10: f(A,B) RESET (C) SET RISING EDGE
11: f(A,B) SET (C) RESET FALLING EDGE
12: f(A,B) RESET (C) SET FALLING EDGE
Default
1
1: (A) SET (B) RESET
Level
ADVANCED
Address
649
Function
This parameter determines the logic function applied to the result of the two
tests allowing calculating the output value.
