SINUS PENTA

PROGRAMMING GUIDE

216/486

P305 MDO4: Output Logic Level

P305 Range

0–1

0: FALSE

1: TRUE

Default

1: TRUE

Level

ADVANCED

Address

905

Function

MDO4 digital output logic function to apply a logic reversal (negation) to the

calculated output signal: (0) FALSE = a logic negation is applied; (1) TRUE = no

negation is applied.
