P350 MPL1: Digital Output Mode
P350 Range
0 ÷ 8
0: DISABLE
1: DIGITAL
2: DOUBLE DIGITAL
3: ANALOG
4: DOUBLE ANALOG
5: DOUBLE FULL
6: BRAKE
7: ABS BRAKE
8: ABS LIFT
Default
1
1: DIGITAL
Level
ADVANCED
Address
950
Function
This parameter defines the operating mode of virtual digital output 1.
The different operating modes are described at the beginning of this chapter.
P351 MPL1: Selecting Variable A
P351 Range
0 ÷ 149
See Table 48
Default
21
D0: Enable
Level
ADVANCED
Address
951
Function
This parameter selects the digital signal used to calculate the value of MPL1
digital output.
It selects an analog variable used to calculate the value of MPL1 d
igital output if
one of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
P352 MPL1: Selecting Variable B
P352
Range
0 ÷ 149
See Table 48
Default
0
D0: Disable
Level
ADVANCED
Address
952
Function
This parameter selects the second digital signal used to calculate the value of
MPL1 digital output.
It selects an analog variable used to calculate the value of MPL1
digital input if
one of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
